39
PARTS GAL. CAP. 40 50 40 50 75
KEY # DESCRIPTION BTU’s in 1000’s NAT/L.P. 36/36 38/38 40/40 48/44 55 NAT.
Kit AVK-2 No. 9001247
32. 3”
I.D. x 13 7/8” Flue Extension Pipe with
9001281 9001281 9001281 9001281 9001281
Gaskets
33. 6”
O.D. x 13 5/8” Vent Extension Pipe
9001275 9001275 9001275 9001275 9001275
34. 3” O.D. x 13 3/8” Flue Pipe 9001284 9001284 9001284 9001284 9001284
35. 6” I.D. x 13 5/8” Vent Pipe 9001278 9001278 9001278 9001278 9001278
36. Rope Gasket 9000712 9000712 9000712 9000712 9000712
37. O-Ring Gasket 9000710 9000710 9000710 9000710 9000710
Kit AVK-3 No. 9001248
38. 3” I.D. x 24 3/8” Flue Extension Pipe with 9001282 9001282 9001282 9001282 9001282
Gaskets
39. 6” O.D. x 24 3/8” Vent Extension Pipe 9001276 9001276 9001276 9001276 9001276
40. 3”
O.D. x 24 3/8” Flue Pipe
9001285 9001285 9001285 9001285 9001285
41. 6”
I.D. x 24 3/8” Vent Pipe
9001279 9001279 9001279 9001279 9001279
42. Rope Gasket 9000712 9000712 9000712 9000712 9000712
43. O-Ring Gasket 9000710 9000710 9000710 9000710 9000710
44. 3”
Flue Elbow
9000718 9000718 9000718 9000718 9000718
45. Rope Gasket 9000712 9000712 9000712 9000712 9000712
46. 6”
Vent Elbow
9000719 9000719 9000719 9000719 9000719
47. Inside Wall Collar 9003168 9003168 9003168 9003168 9003168
48. 6”
Vent Wall Assembly
9003166 9003166 9003166 9003166 9003166
49. Vent Cap Assembly 9003165 9003165 9003165 9003165 9003165
50. 24”
Diameter Drain Pan w/Side Drain
9002769 9002769 9002769 9002769 —
51. 28”
Diameter Drain Pan w/Side Drain
— — — — 9001608
52. 24”
Base Stand
9001422 9001422 9001422 9001422 —
53. Wire Grill Protector 9000915 9000915 9000915 9000915 9000915
54. Dip Tube *9002365 9001595 *9002365 *9002361 *9001598
55. 6” Vent Wall Assembly 9000724 9000724 9000724 9000724 9000724
56. Brown-Porcelain Vent Cap Assembly 9000725 9000725 9000725 9000725 9000725
57. Piezo Ignitor w/Bracket 9003410 9003410 9003410 9003410 9003410
REPAIR PARTS LIST
(cont’d.)
*NOTE: Some models are factory equipped with a special dip tube to retard a build-up of mineral deposits precipitating from
the water supply over time. This is not illustrated and is not a replaceable part.
Now that you have purchased this water heater, should a need ever exist for repair parts or service, simply contact the
company it was purchased from or direct from the manufacturer listed on the rating plate on the water heater.
Be sure to provide all pertinent facts when you call or visit.
Selling prices will be furnished on request or parts will be shipped at prevailing prices and you will be billed
accordingly.
The model number of your water heater will be found on the rating plate located above the gas control valve.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
MODEL NUMBER
TYPE GAS
SERIAL NUMBER PART DESCRIPTION
THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.
