State PR6 75 XODS - Manual (Page 37)

37
PARTS GAL. CAP. 40 50 40 50 75
KEY # DESCRIPTION BTU’s in 1000’s NAT/L.P. 36/36 38/38 40/40 48/44 55 NAT.
1. Access Door Clips (Pkg. 2) 9000694 9000694 9000694 9000694 9000694
2. Right Access Door w/Gasket 9000695 9000695 9000695 9000695 9000695
3. Left Access Door w/Gasket 9000696 9000696 9000696 9000696 9000696
4. Burner Orifice (Nat.) 9005165 9005170 9001700 9005171 9001701
(Drill Size) #36 #35 #33 1/8 #30
4. Burner Orifice (Nat.) Hi-Altitude 9005928 9001886 9005165 9001700 9005172
(Drill Size) #39 #37 #36 #33 #31
4. Burner Orifice (L.P.) LHT 9004005 9004005 9002134 9002130 —
(Drill Size) #51 #51 #50 #49
4. Burner Orifice (L.P.) Hi-Altitude/LHT 9002129 9002129 9004005 9002134 —
(Drill Size) #52 #52 #51 #50
5. Thermocouple 9000876 9000876 9000876 9000876 9002002
6. Gas Control Valve (Nat.) 9000249 9000249 9000249 9000249 9000249
6. Gas Control Valve Propane (L.P.) 9002123 9002123 9002123 9002123 9002123
7. Gas Manifold (Nat.) 9002413 9002413 9002413 9002413 9003046
7. Gas Manifold (L.P.) 9002415 9002415 9002415 9002415 —
8. Pilot Tubing w/Fittings 9000278 9000278 9000278 9000278 9000278
9. Burner (Nat.) 9002411 9002411 9002411 9002411 9003040
9. Burner Propane (L.P.) 9002411 9002411 9002411 9000349 —
10. Inner Door 9000281 9000281 9000281 9000281 9000281
11. Pilot (Nat.) w/electrode 9003084 9003084 9003084 9003084 9003084
11. Pilot Propane (L.P.) w/electrode 9003085 9003085 9003085 9003085 —
12. Drain Valve 9000058 9000058 9000058 9000058 9001588
13. Jacket Clips (Pkg. 8) 9001305 9001305 9001305 9001305 9001305
14. Secondary Anode w/Nipple* 9000705 9000705 9000705 9000705 9000705
15. Temperature-Pressure Relief Valve 9000728 9000728 9000728 9000728 9000728
16. Anode Rod 9000707 9000279 9000707 9000279 9000734
17. Nipple 9000399 9000399 9000399 9000399 9002298
18. Flue Baffle (Nat.) 9000709 9002836 9002837 9001288 9002297
18. Flue Baffle (L.P.) 9000709 9000806 9001287 9001288 —
19. Flue Adaptor — — 9001289 9001290 9001290
20. Adaptor Gasket — — 9001291 9001292 9001292
21. Adaptor Plate w/Gasket — — 9001293 9001294 9001294
Standard Kit No. 9000687
22. O-Ring Gasket 9000710 9000710 9000710 9000710 9000710
23. 3” I.D. x 9.5”
Flue Extension Pipe with
9000711 9000711 9000711 9000711 9000711
Gaskets
24. Rope Gasket 9000712 9000712 9000712 9000712 9000712
25. 3” I.D. x 5 1/2” Vent Extension Pipe 9000713 9000713 9000713 9000713 9000713
Kit AVK-1 No. 9001246
26. 3”
I.D. x 7 7/8” Flue Extension Pipe with 9001280
9001280 9001280 9001280 9001280
Gaskets
27. 6”
I.D. x 8 1/8” Vent Pipe
9001277 9001277 9001277 9001277 9001277
28. 6” O.D. x 8 1/8” Vent Extension Pipe 9001274 9001274 9001274 9001274 9001274
29. 3” O.D. x 8 3/8” Flue Pipe 9001283 9001283 9001283 9001283 9001283
30. Rope Gasket 9000712 9000712 9000712 9000712 9000712
31. O-Ring Gasket 9000710 9000710 9000710 9000710 9000710
REPAIR PARTS LIST
(cont’d.)
