2
WARNING
WATER HEATERS EQUIPPED FOR ONE TYPE GAS ONLY: This
water heater is equipped for one type gas only. Check the rating
plate near the gas control valve for the correct gas. DO NOT USE
THIS WATER HEATER WITH ANY GAS OTHER THAN THE ONE
SHOWN ON THE MODEL RATING PLATE. Failure to use the cor-
rect gas can cause problems which can result in DEATH, SERIOUS
BODILY INJURY, OR PROPERTY DAMAGE. If you have any ques-
tions or doubts consult your gas supplier or local utility.
WARNING
A fire can start if combustible materials such as clothing, cleaning
materials, or flammable liquids are placed against or next to the
water heater.
WARNING
INSTALLATIONS IN AREAS WHERE FLAMMABLE LIQUIDS
(VAPORS) ARE LIKELY TO BE PRESENT OR STORED (GARAGES,
STORAGE, AND UTILITY AREAS, ETC): Flammable liquids (such
as gasoline, solvents, propane (LP) or butane, etc.), all of which
emit flammable vapors, may be improperly stored or used in such
areas. The gas water heater pilot light or main burner can ignite
such vapors. The resulting flashback and fire can cause death or
serious burns to anyone in the area, as well as property damage.
If installation in such areas is your only option, then the installa-
tion must be accomplished in a way that the pilot flame and main
burner flame are elevated from the floor at least 18 inches. While
this may reduce the chances of flammable vapors from a floor
spill being ignited, gasoline and other flammable substances
should never be stored or used in the same room or area contain-
ing a gas water heater or other open flame or spark producing
appliance.
NOTE: Flammable vapors may be drawn by air currents from
other areas of the structure to the appliance.
WARNING
HOTTER WATER CAN SCALD: Water heaters are intended to
produce hot water. Water heated to a temperature which will
satisfy space heating, clothes washing, dish washing, and other
sanitizing needs can scald and permanently injure you upon
contact. Some people are more likely to be permanently injured
by hot water than others. These include the elderly, children,
the infirm, or physically/mentally handicapped. If anyone using
hot water in your home fits into one of these groups or if there
is a local code or state law requiring a certain temperature
water at the hot water tap, then you must take special precau-
tions. In addition to using the lowest possible temperature set-
ting that satisfies your hot water needs, a means such as a mix-
ing valve, shall be used at the hot water taps used by these peo-
ple or at the water heater. Mixing valves are available at plumb-
ing supply or hardware stores. Follow manufacturers instruc-
tions for installation of the valves. Before changing the factory
setting on the thermostat, read the “Temperature Regulation”
section in this manual.
WARNING
BEFORE LIGHTING PROPANE (L.P.) GAS WATER HEATERS:
Propane (L.P.) gas is heavier than air. Should there be a leak in
the system, the gas will settle near the ground. Basements,
crawl spaces, skirted areas under manufactured (mobile)
homes (even when ventilated), closets and areas below ground
level will serve as pockets for the accumulation of this gas.
Before attempting to light or relight the water heater’s pilot or
turning on a nearby electrical light switch, be absolutely sure
there is no accumulated gas in the area. Search for odor of gas
by sniffing at ground level in the vicinity of the appliance. If
odor is detected, follow steps indicated at “For Your Safety” on
the cover page of this manual then leave the premises.
WARNING
Improper installation, adjustment, alteration, service or mainte-
nance can cause DEATH, SERIOUS BODILY INJURY, OR PROP-
ERTY DAMAGE. Refer to this manual or consult your local gas
utility for assistance.
WARNING
At the time of manufacture this water heater was provided with
a combination temperature-pressure relief valve certified by a
nationally-recognized testing laboratory that maintains periodic
inspection of production of listed equipment or materials, as
meeting the requirements for Relief Valves and Automatic Gas
Shutoff Devices for Hot Water Supply Systems, and the current
edition of ANSI Z21.22 and the code requirements of ASME. If
replaced, the valve must meet the requirements of local codes,
but not less than a combination temperature and pressure relief
valve certified as meeting the requirements for Relief Valves
and Automatic Gas Shutoff Devices for Hot Water Supply
Systems, ANSI Z21.22 by a nationally recognized testing labo-
ratory that maintains periodic inspection of production of listed
equipment or materials.
The valve must be marked with a maximum set pressure not to
exceed the marked hydrostatic working pressure of the water
heater (150 lbs. p.s.i.) and a discharge capacity not less than
the water heater input rate as shown on the model rating
plate. (Electric heaters - watts divided by 1000 x 3412 equal
BTU/Hr. rate.)
Your local jurisdictional authority, while mandating the use of a
temperature-pressure relief valve complying with ANSI Z21.22
and ASME, may require a valve model different from the one
furnished with the water heater.
Compliance with such local requirements must be satisfied by
the installer or end user of the water heater with a locally pre-
scribed temperature-pressure relief valve installed in the desig-
nated opening in the water heater in place of the factory fur-
nished valve.
For safe operation of the water heater, the relief valve must not
be removed from it’s designated opening or plugged.
The temperature-pressure relief valve must be installed directly
into the fitting of the water heater designated for the relief
valve. Position the valve downward and provide tubing so that
any discharge will exit only within 6 inches above, or at any
distance below the structural floor. Be certain that no contact is
made with any live electrical part. The discharge opening must
not be blocked or reduced in size under any circumstances.
Excessive length, over 30 feet, or use of more than four elbows
can cause restriction and reduce the discharge capacity of the
valve.
No valve or other obstruction is to be placed between the
relief valve and the tank. Do not connect tubing directly to dis-
charge drain unless a 6 ″ air gap is provided. To prevent bodily
injury, hazard to life, or property damage, the relief valve must
be allowed to discharge water in quantities should circum-
stances demand. If the discharge pipe is not connected to a
drain or other suitable means, the water flow may cause prop-
erty damage.
The Discharge Pipe:
—Must not be smaller in size than the outlet pipe size of the
valve, or have any reducing couplings or other restrictions.
—Must not be plugged or blocked.
—Must be of material listed for hot water distribution.
—Must be installed so as to allow complete drainage of both
the temperature-pressure relief valve, and the discharge pipe.
—Must terminate at an adequate drain.
—Must not have any valve between the relief valve and tank.
General Safety
