Checkers Rocket II LED Lights User Manual
New rocket™ ii led whip lights, Installation instructions, Instructions for adaptable 2, 4, and 6 led lights

620 COMPTON ST • BROOMFIELD, COLORADO, USA 80020
800-438-9336 •
www.checkersindustrial.com
Ver: RCKT2INST-3/14
PARTS LIST
1. Lower Threaded Base
2. O-Ring
3. Clear Lens
4. Circuit Board
5. Upper Threaded Base
1. Remove lower base from upper base
2. Remove O-ring from the lower base
3. Slide threaded lower base over the lamp
socket with the female threads up
4. Slide the O-ring over the lamp socket
5. Push the O-ring to the bottom of the
lower base
6. Place the upper base and housing on the
lamp socket. Turn the housing without
pushing down on the lamp socket until
the upper housing falls into place on the
lamp socket.
7. Thread the lower base to the upper base
1
2
3
4
5
1
5
6
7
2
3
4
INSTALLATION INSTRUCTIONS
NEW ROCKET™ II LED WHIP LIGHTS
From the Experts in Industrial Safety
INSTRUCTIONS FOR ADAPTABLE 2, 4, AND 6 LED LIGHTS
Patent Pending
