HDSL2 for General Distribution Installation and Maintenance Practice HDSL New Enhanced Feature Overview
61223HDSL2L2-5B B-7
Figure B-4. Splice Histogram Screen
Compatibility
The H2TU-C and H2TU-R both run local detectors; therefore, a splice-detection capable
H2TU-C will be able to detect bad splices up to slightly more than half the circuit length.
Likewise, a splice detection capable H2TU-R will be able to detect bad splices up to slightly
more than half the circuit from the remote end. With older (non-splice detection units) the
splice-detection capable units will not receive Embedded Operations Channel (EOC) messages
from the older units so visibility from the other end is lost. Splice detection support is not
available for two-wire repeaters.
Circuit ID: 11/05/04 09:29:45
Press ESC to return to previous menu
Splice Histogram Screen
H2TUC Press C to Change H2TUC
Splice | Splice |
(feet) | H2TUC H2TUR (feet) | H2TUC H2TUR
------ | ----- ----- ------ | ----- -----
0000 | 00 00 3890 | 00 00
0250 | 09 00 4170 | 00 00
0530 | 00 00 4455 | 00 00
0810 | 00 00 4740 | 00 00
1090 | 00 00 5025 | 00 00
1370 | 00 00 5310 | 00 00
1650 | 00 00 5595 | 00 00
1930 | 00 00 5880 | 00 00
2210 | 00 00 6165 | 00 00
2490 | 00 00 6450 | 00 00
2770 | 00 00 6735 | 00 00
3050 | 00 00 7020 | 00 00
3330 | 00 00 7305 | 00 00
3610 | 00 00 7590 | 00 00
