4 layout diagram, For km780v model – AMD KM780V User Manual
Page 7
4
1-4 Layout Diagram
For KM780V model
8MBit Flash SPI ROM BIOS
Floppy Connector
Front Panel Connector
ATA 133 IDE
Conn.
(IDE1)
CPU Socket AM2+
ATX Power Conn.
Serial-ATAII Connector
(SATA1~6)
PCI Slots
PS2 KB/Mouse
Port
CPU FAN
Audio Connector
USB Port
RJ-45 Over
USB Connector
Audio Header
DDR2 Socket x2
SYSFAN2
ATX 12V Power Connector
Realtek ALC662HD
Audio Decode
Speaker Header
USB headers
PCI Express x16
Power LED Header
AMD780V
AMD SB700 Chipset
Keyboard/USB
Power (JP1)
RTL8111C Gigabit LAN
CD Audio In
HDMI_SPDIF
COM Header
SYSFAN1
HDMI
Connector
PS/2 Mouse
PS/2 Keyboard
Line-OUT
MIC-IN
VGA Connector
DVI Connector
Line-IN
USB Connector
RJ-45 LAN
VGA over DVI
Connector
Clear CMOS Jumper
(JBAT)
DDRII 128MB sideport
HDMI Connector
Coaxial
SPDIF_Out Connector
SPDIF_Out
Connector
