3
1-3 Specification
Spec Description
Design ∗ Micro ATX form factor 4 layers PCB
∗ size: 24.5x20.0cm
Chipset ∗
AMD780V Chipset and AMD SB700 Chipset
CPU Socket AM2+
∗
Support 64bit AMD AM2+ 940-Pin package utilizes Flip-Chip Pin Grid
Array package compatible processor
∗
Support for HTT 1GHz dual core AMD Phenom processors
∗
Support HT 3.0 AMD Athlon 64 X2 processor
Memory Socket
∗
240-pin DDR2 Module socket x 2
∗
Support 2 pcs DDR2 1066 / DDR2 800/DDR2 667 Modules
Expandable to 4GB
Expansion Slot
∗
PCI-Express2.0 x16 by16 lane 1pcs delivers up to 16 GB/s of
concurrent bandwidth.
∗
32-bit PCI slot x 2 pcs
Integrate IDE and
Serial ATA2 RAID
∗
One IDE controllers support PCI Bus Mastering, ATA PIO / DMA and
the ULTRA DMA 33/66/100/133 functions that deliver the data transfer
rate up to 133 MB/s.
∗
Six Serial ATA2 ports provide 300 MB/sec data transfer rate with
RAID 0, 1, JBOD functions.
Integrated VGA
∗
780V chipset integrated with HD3100 graphics with 350 MHz core
Frequency
∗
DirectX 10.0 compliant 2D /3D graphics processor
LAN
∗
Integrated RTL 8111C PCI-E 10/100 /1000 LAN chip
∗
Supports Fast Ethernet LAN function provide 10/100/1000 Mb /s data
transfer rate
Audio
∗
6-channelALC662 HD Audio Codec integrated
∗
Audio driver and utility included
BIOS ∗
Award 8MB SPI Flash ROM
Multi I/O ∗
PS/2 keyboard and PS/2 mouse connectors
∗
VGA Connectorx1
∗
DVI Connectorx1
∗
HDMI Connector x1
∗
USB2.0 port x 4 and headers x 2
∗
Audio connector (Line-in, Line-out, MIC/ 6CH Audio)
∗
Floppy disk drive connector x1
∗
Hard disk drive connector x1
∗
Serial port header x1
∗
HDMI_SPDIF Out header x1
