Wireless HD AV Transmitter & Receiver Kit
9
5.3.2
Remote Control
1. A-1 Select HDMI IN 1 device. Connect HDMI IN 1 to HDMI OUT A Channel.
2. A-2 Select HDMI IN 2 device. Connect HDMI IN 2 to HDMI OUT A Channel.
3. A-3 Select HDMI IN 3 device. Connect HDMI IN 3 to HDMI OUT A Channel.
4. A-4 Select HDMI IN 4 device. Connect HDMI IN 4 to HDMI OUT A Channel.
5. B-1 Select HDMI IN 1 device. Connect HDMI IN 1 to HDMI OUT B Channel.
6. B-2 Select HDMI IN 2 device. Connect HDMI IN 2 to HDMI OUT B Channel.
7. B-3 Select HDMI IN 3 device. Connect HDMI IN 3 to HDMI OUT B Channel.
8. B-4 Select HDMI IN 4 device. Connect HDMI IN 4 to HDMI OUT B Channel.
Image 4
