10
Installation and user manual
Rear Panel Connections
(1) RS232
Serial Communication
(2) AUDIO OUTPUT
Audio output
(3) COMPOSITE VIDEO OUT
Composite Video Output
(4) VIDEO IN
16 Camera inputs (1.0v p-p, 75 Ω)
(5) PTZ CAMERA CONTROLLER
Serial Communication for Pan / Tilt Camera
(6) KEYBOARD CONTROLLER
Serial Communication for P/T/Z Control Keyboard
(7) ALARM OUT
Alarm output port
(8) SENSOR IN
16 Sensor input ports
⑨ ⑩ ⑪ ⑫ ⑬ ⑭
① ② ③ ④ ⑤⑥⑦⑧
