Flaming River FR312KT 63-82 Corvette Rack User Manual

Page 2

background image

- 1 –

11/28/2005

Index

NOTE: Before beginning you must first measure the width of your
front end from LEFT outer tie rod end zerk (grease) fitting to the
RIGHT outer tie rod end zerk fitting to determine the overall width of
your front end. Write dimension here for further reference


Installation hardware and inventory

PG 2

Section 1 Original System Removal

A. Steering Box & Linkage Removal

PG 3


Section 2 Installation of The Flaming River Rack & Cradle

A. Installation of Rack and Cradle

PG 4

Section 3 Universal Joint Installation

A. Universal Joint and Steering Shaft Installation

PG 5-6



Torque Specs

PG 6

Template

PG 7


IMPORTANT!! For safety, before starting, disconnect both battery
cables and ensure the vehicle is properly supported by jack stands.

We recommend that you always install new outer tie rod ends when installing
this kit.
We highly recommend a professional alignment to set the proper alignment
settings

.

Warranty Disclaimer

Because of their intended usage, the manufacturer makes no warranties whatsoever expressed
or implied, oral or written, to purchasers of their products regarding performance, safety, fit,
merchantability or length of service. Purchasers are responsible for selection of proper goods and
must rely on their own skill or judgment that such goods are suitable for the purchaser’s
application.
