Page 2
ONE-YEAR WARRANTY
We warrant our products to be free of defects in material
and workmanship for one year from the date of original pur-
chase. Write for full warranty details.
This warranty does not apply to product which has been
used on boats weighing more than 300 pounds (136 kg).
REPLACEMENT PARTS
Part
Qty.
No.
Description
Req’d
R1461A
Transom Track
2
R1481A
Strut
2
R1481B
Tire with Innertube, 4 x 16"
2
(10 x 41 cm), and Hub
R1465A
Tire with Innertube, 4 x 16"
2
(10 x 41 cm)
R1461B
Lockpin, 5/16" (8 mm)
4
3465 Diablo Avenue, Hayward, CA 94545, U.S.A.
Phone (510) 732-9229 • Fax (510) 732-9188
For information about our other fine products,
visit www.davisnet.com
1481_Ins.pdf April 2006
#1481
Launching Wheels for Boats,
Extra Capacity
1/4" Nyloc Nut
1/4" Stainless
Steel Washer
Sealing
Compound
Apply at bolt holes
on transom
Nylon Spacer
(use optional)
Lightweight Oil
(Davis Max-Lube™
#422 or
equivalent)
2" Bolt
(4 places)
Transom
Track
R1461A
6
1
/
2
" Bolt
1/2" Nyloc
Nut
1/2" Stainless Steel
Washer
1/2" Nylon
Washer
Tire, Innertube and
Hub
R1481B
Tire with Innertube
R1465A
Nylon
Bushing
Strut
R1481A
1/4" Drill
Holes
Lockpin
R1461B
Wooden
Backup Block
recommended for all
metal transoms
