3

Wiring Diagram

Refer to this wiring diagram to connect the DriveRight 600

E

digital inputs and to

connect the Adapter Cable to a DriveRight 600

E

display, GPS/Wireless Interface

Module, or SmartCard Reader..

Note:

Refer to the manual that came with your product for further wiring

instructions. Manuals are available online at www.davisnet.com/support.

Display

Adapter Cable

Red Wire with

Fuseholder

In-Line

Splice

Butt

Splices

(2)

Blue Wires

with

In-Line

Fuses

Green

Yellow

Red

Black

Unswitched

+12V

Ground

Digital

Inputs

1

2

E

GPS/Wireless

Inteface Module

SmartCard

Reader

To OBDII Signal,

Reed Switch Speed Signal,

or

VSS Speed Signal

Red

or

or
