SPECIAL INTERMEDIATE FRONT SERVO NOTE
Sometimes the Intermediate Front Servo will fall out when lowering the
spacer plate. If so, be sure to reinstall per drawing.
CAUTION
Be sure that Manual
Control Valve lines up
with selector pin on the
selector lever!
Selector Lever
1965-70
Servo Spring
Servo Pin
Washer
Oil Seal Ring
Spring Retainer
Servo Piston
Servo Spring
Servo Pin
Retainer Ring
Teflon Oil Seal Ring
Spring Retainer
Servo Piston
1971-Up
Fig. 2
123456789012345678
123456789012345678
123456789012345678
123456789012345678
123456789012345678
123456789012345678
123456789012345678
123456789012345678
Fig. 2A
Remove Direct Clutch Drum
Center Seal
Install 24117
Freeze Plug
here
