Part #23252/#23253 3 4/84,5/99,9/01,5/27/04,7/9/08
FIGURE #5
Sometimes the front servo will fall out when lowering the
spacer plate in Step #6. If so, be sure to reinstall per above.
FIGURE #1
KICKDOWN ASSEMBLY
FIGURE #2
GEAR SHIFT LINKAGE
Servo Spring
Servo Pin
Washer
Oil Seal Ring
Servo Piston
Spring Retainer
FIGURE #4
OIL PUMP SCREEN
FIGURE #3
GOVERNOR SCREEN LOCATIONS
A - Chevy Only
A & B - Buick, Olds., Pontiac
Front Servo Was
Located Here.
A
B
