TigerClamp Location Chart
7. Using the bracket as a template,
drill six 3/8” holes through the floor
pan.
8. Hold the reinforcement plate up
against the bottom of the floor pan.
Drop two 3/8” x 1 ¼” bolts through
the inside two holes. The four outer
holes also pass through the door bar
flange and require 3/8” x 1 ¾” bolts.
The outer rear bolt must be installed
from the bottom up to clear the bar.
Installation complete!
