8. Place the Shockwave up into the
coil spring pocket with the stud
protruding through the factory shock
hole. See diagram below. The
factory shock hole may need to be
drilled out to ¾”.

9. Fasten the Shockwave to the
factory lower control arm using two
3/8” x 1 ¼” bolt, flat washers and
nylok nuts. The T-bar will sit on top
of the lower arm. (This picture
shows the StrongArms)

10. Ride height will be around 90-100
psi, but will vary to driver preference.

1. Stud top base

2. Lower Delrin ball half

3. Upper Delrin ball half

4. Aluminum cap

5. 9/16” Nylok jam nut

6. Threaded stud

7. Adjustment knob (SA Only)

8. Screw

9. Snap ring
