Ridetech 11370199 - Manual (Page 8)

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Hardware Kit: Part # 99010013
44 ½ x 1 ½ USS bolt C-notch, Upper bridge, & upper bar mount
44 ½ USS Nyloc Nuts C-notch, Upper bridge, & upper bar mount
88 ½ SAE Flat washers C-notch, Upper bridge, & upper bar mount
8 5/8 x 6 ½ SAE Gr.8 Bolts Lower Bridge
8 5/8 SAE Gr. 8 Nyloc Nuts Lower Bridge
16 5/8 SAE Gr. 8 Flat washers Lower Bridge
7 5/8 x 2 ¾ SAE Gr. 8 Bolts Bar to bracket
7 5/8 SAE Gr.8 Thin Nyloc nuts Bar to bracket
2 3/8 x 2 ½ USS Bolts Carrier bearing bracket
2 3/8 USS Nyloc nuts Carrier bearing bracket
8 3/8 SAE Flat washers Carrier bearing bracket & Air Spring to mounts
2 ½ x 2 ½ USS bolts Lower Shock mount
2 ½ USS nyloc nuts Lower Shock mount
3 5/16 x 2 USS Bolts Panhard bar axle mount
5 5/16 SAE Flat washers Panhard bar axle mount & brake line bracket
3 5/16 Lock washers Panhard bar axle mount
1 5/16 x 1 ¼ USS Bolt Brake Line Bracket
1 5/16 USS nyloc nut Brake Line Bracket
1 ½ x 1 ½ Fender Washer Panhard bar to bracket
1 7/16 USS Nyloc nut Panhard bar to bracket
4 3/8 x 1 USS Bolts Air Spring to mounts
4 3/8 Lock washers Air Spring to mounts
Part # 11370809
88-98 C1500 AirBar Black Series Shock Kit
For Use w/Airbar
Shock:
2 22569999 RQ Smooth Body Shock Cartridge
4 70011138
3/4” ID Shock Bushing
2 90002103 5/8” ID Shock Sleeve
2 90002102
1/2” ID Shock Sleeve
