Part # 12045400
55-57 T-Bird Rear Black Series Shockwaves
Shockwave Assembly:
2
20259999 5” stroke Black Series shock
2 20290799 4” diameter Black Series bellow assembly
2 90001087 Internal bump stop
2 90001994 Bearing – 1” O.D. x .625” I.D.
2 90001995 Snap ring
2 90002000 Tall threaded stud
2 90001835 2.75” stud top base
Components:
2
31954201 ¼” npt x ¼” tube 90 degree airline fitting
2 90001830 Aluminum cap for Delrin ball
2 90001903 Delrin ball top half
2 90001904 Delrin ball bottom half
2 90001621 Eye to Stud adapter bracket – Lower mount
4 90002043 Bearing spacers - .5” I.D.
Hardware:
2
99122001 12mm Nylok Nut Stud top
2 99501018 ½” x 1 ½” Carriage bolt Eye to stud adapter
2 99502001 ½” USS Nylok nut Eye to stud adapter
2 99503003 ½” USS flat washer Eye to stud adapter
2 99501010 ½” x 2 ¼” SAE bolt Shock to bracket
2 99502003 ½” SAE Nylok nut Shock to bracket
