350 S. St. Charles St. Jasper, In. 47546

Ph. 812.482.2932 Fax 812.634.6632

www.ridetech.com

Part # 11280702

65-70 Impala Master Series DA Rear Shock Kit

Components:

2

21269999

6” stroke Master Series Double Adjustable shock

2

90001901

3” tall Master Series eyelet

2

90001632

Bump stop

4

90001686

.625” bearing

4

90001900

Snap ring for bearing

2

90002010

Extended T-bar – Installed in shock body

4

90001980

Snap ring for T-bar

4

90002042

Aluminum bearing spacer - .625” I.D.

2

90001619

Round head cantilever pin

2

90000471

Aluminum spacer

Hardware:

2

99623001

5/8” SAE Gr. 8 flat washer Cantilever pin

4

99371004

3/8” x 1 ¼” USS bolt

Shock to frame

8

99373003

3/8” SAE flat washer

Shock to frame

4

99372002

3/8” USS Nylok nut

Shock to frame
