Installation Instructions
1. The upper shock mount must be
welded to the frame. It may need to be
cut down to match the stroke of the air
spring and suspension. Make sure that
when the suspension is fully
compressed the shock is about ¼”
from being fully compressed. Just tack
weld the mount for now and install the
lower shock stud and shock. The
upper mount will use a 2 ½” x ½” bolt
and nyloc. Check to make sure the
shock does not bottom out when the
suspension is fully compressed. If
the shock bottoms out it could damage
the shock or shock mounts.
