Ridetech 11360602 - Manual

Part # 11360602
73-87 C-10 Master Series DA Front Shock Kit
For Use w/ Lower StrongArms
Shock Assembly:
2 21239999 3.5” stroke Master Series double adjustable shock
6 90001632 Compression bump stop
2 90001834 Short Stud top – 2”
2 90001686 .625” bearing
2 90001900 Snap ring for bearing
Components:
2 90001906 Stud top base
2 90001902 Aluminum cap for Delrin ball
2 90001903 Upper Delrin ball half
2 90001904 Lower Delrin ball half
2 90001619 Cantilever pin w/ hardware
4 90002042 Aluminum bearing spacer - .625” I.D.
2 90000471 Aluminum spacer
1 90002303 Driver side upper shock bracket – bolt-on
1 90002304 Passenger side upper shock bracket – bolt-on
Hardware:
8 99371004 3/8” x 1 ¼” USS bolt Upper shock bracket to frame
8 99372002 3/8” USS Nylok nut Upper shock bracket to frame
16 99373003 3/8” SAE flat washer Upper shock bracket to frame
2 99623001 5/8” SAE flat washer Cantilever pin
4 99562002 9/16” SAE jam nut Upper shock stud
