Ridetech 11370502 - Manual

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11370502
88-98 C-1500 Front Master Series DA Shock Kit
For Use w/ CoolRide
Shock Assembly:
2 21229999 2.6” stroke double adjustable shock
6 90001632 Bump stop
2 90001906 Stud top – 2”
2 90001686 .625” bearing
2 90001900 Snap ring
Components:
2 90001834 Aluminum stud top base – 2”
2 90001902 Aluminum cap for Delrin ball
2 90001903 Delrin ball – Lower half
2 90001904 Delrin ball – Upper half
4 90002042 Bearing spacer - .625” I.D.
2 90001619 Cantilever pin w/ hardware
2 90000471 Aluminum shock spacer
1 90002315 Driver side upper shock bracket
1 90002316 Passenger side upper shock bracket
Hardware:
6 99371004 3/8” x 1-1/4” USS bolt Upper shock mount to frame
6 99372002 3/8” USS Nylok nut Air spring and shock mounting
12 99373003 3/8” SAE flat washer Air spring and shock mounting
2 99623001 5/8” Gr. 8 flat washer Stud top hardware
2 99632002 5/8” SAE Nylok jam nut Stud top hardware
