350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11059100
58-64 Impala Front MuscleBar
w/ PosiLinks
Components:
1 90000127 1 ¼” Diameter sway bar
2 90000124 Sway bar arm
1 90000736 Driver side frame bracket
1 90000737 Passenger side frame bracket
2 90001098 1 ¼” I.D. Polyurethane bushing
2 90000922 12mm straight PosiLink
2 90000921 12mm 90 degree PosiLink
2 90000089 T-bushing for lower control arm
1 90001092 Tube of lithium grease
2 99250001
¼” – 28 straight grease fitting
2 99125001 12 x 1.75 x 45mm stud In PosiLink (use Loctite)
Hardware Kit: 99010039
4
99122001 12mm Nylok nut PosiLink
2 99433002
7/16” SAE flat washer
PosiLink to lower arm
6 99431001 7/16” x 1” USS bolt Frame bracket to frame
6 99432001
7/16” USS Nylok nut
Frame bracket to frame
12 99433002 7/16 SAE flat washer Frame bracket to frame
4 99371003
3/8” x 1” USS bolt
Frame bracket to frame
4 99372002 3/8” USS Nylok nut Frame bracket to frame
8 99373003
3/8” SAE flat washer
Frame bracket to frame
8 99371017 3/8” x 1” USS button head Attaches sway bar arm to bar
8 99373005
3/8” lock washer
Attaches sway bar arm to bar
