350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11239100
64-67 GM “A” Body Front MuscleBar
Components:
1 90000156 Front sway bar (37.875”)
1 90000148 Driver side arm
1 90000149 Passenger side arm
2 90000152 Frame plate
2 90000150 Frame bracket
2 90000926 90 degree 10mm PosiLink
2 90000924 Straight 10mm PosiLink
4 90000717 T-bushing (PosiLink to lower arm)
2 90001099 Polyurethane frame bushing - 1.5” I.D.
2 99250001 ¼” - 28 straight grease zerk
1 90001092 Tube of Lithium grease
2 99115001 10mm x 1.5 x 36mm stud (use Loctite) In PosiLink
Hardware Kit: 99010040
2 99371028 3/8” x 3/4" USS Flat head Allen bolt Frame plate to frame
4 99371004 3/8” x 1 ¼” USS bolt Frame bracket
14 99373003 3/8” SAE flat washer Frame bracket / Sway bar arm to bar
10 99373005 3/8” lock washer Frame bracket / Sway bar arm to bar
6 99371017 3/8” x 1” Button head Allen bolt Sway bar arm to bar
4 99112002 10mm Nylok nut PosiLink
2 99502003 ½” SAE Nyloc jam nut Steering arm
