Installation Instructions
*****This sway bar is designed for use with our front StrongArms*****
3. Bolt the PosiLinks to the sway
bar and lower control arm. The
holes in the arm and bar are larger
than the PosiLink studs, so T-
bushing are supplied and must be
installed on the top and bottom of
the bar and the control arm tabs.
4. Check sway bar clearance
through full suspension travel and
from lock to lock.
Make sure that the PosiLinks do
not bind.
1. Apply lithium grease to the poly
bushings and slide them over the
sway bar.
2. Slide the bushing strap over the
bushing. Bolt the sway bar to the
frame using the 10mm x 30mm
bolts supplied.
Note: Some trucks did not come
with a factory sway bar. In this
case the holes may need to be
drilled and tapped.
