Ridetech 11051099 - Manual

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11051099
58-64 Impala Front CoolRide Kit
For Use with Stock Lower Arms
Components:
2 90006873 F6873- Firestone air spring (224c)
2 90000013 Upper air spring cup bracket
2 90000012 Lower air spring plate
Hardware:
2 99371001 3/8” x ¾” USS bolt Air spring to lower plate
4 99371003 3/8” x 1” USS bolt Lower plate to control arm
10 99372002 3/8” USS Nylok nut Air spring mounts
14 99373003 3/8” SAE flat washer Air spring mounts
2 99373005 3/8” lock washer Air spring to lower plate
2 99435002 7/16” x 8” studs (customer will cut off to 6 ½ inches)
2 99433002 7/16” USS flat washer Upper cup to frame
2 99432001 7/16” USS Nylok nut Upper cup to frame
2 99371011 3/8” x 6 ½” USS bolt Sway bar end link
