10. Bolt the lower mount to the
bottom of the air spring using a 3/8” x
3/4" bolt, lock washer and flat washer.
Before tightening, make sure it aligns
with the lower arm.
11. The hole in the tab on the lower
mount will align with the parking brake
cable clamp. It will be held tight with
a 5/16” x 1” bolt, lock washer, and flat
washer.
12. Make sure that the air spring
cannot rub on anything at anytime.
This will result in air spring failure
and is a not a warrantable situation.
13. Ride height on this air spring is
approximately 5” tall, but may vary to
driver preference.
This is the driver bracket looking down
at the top of it.
The tab goes to the rear of the car.
