350 S. St. Charles St. Jasper, In. 47546

Ph. 812.482.2932 Fax 812.634.6632

www.ridetech.com

Part # 11214099

82-02 Rear Camaro CoolRide Kit

Components:

2

90009000

Tapered sleeve air spring

1

90000416

Upper air spring bracket – Driver side

1

90000417

Upper air spring bracket – Passenger side

2

90000290

Lower rear air spring roll plate

Hardware:

4

99371001

3/8” x 3/4" USS bolt

Air spring to upper bracket

4

99373005

3/8’ lock washer

Air spring to upper bracket

6

99373003

3/8” SAE flat washer

Air spring mounts

2

99371027

3/8” x 1” carriage bolt

Upper bracket to car

2

99372002

3/8” USS Nylok nut

Upper bracket to car
