Part # 11251099
62-67 Nova Front CoolRide
Components:
2 90006781 Air spring – 6.5” diameter, double convoluted, ¼” port
1 90000382 Driver’s side plate, place on top of fender
1 90000383 Passenger side plate, place on top of fender
2 90000391 Upper bracket (angled, 5 3/8” tall)
2 90000377 Lower air spring mount (sm. Flat plate)
2 90001082 Short bump stops
Hardware:
2 99435001 7/16” x 6” stud Upper bracket & plate to strut tower
2 99432001 7/16” USS Nylok nut Upper bracket & plate to strut tower
2 99433002 7/16 “SAE washer Upper bracket & plate to strut tower
4 99371027 3/8” x 1” carriage bolt Lower plate to upper arm
8 99372002 3/8” USS Nylok nut Air spring to upper bracket
10 99373003 3/8” SAE flat washer Air spring mounting
2 99371001 3/8” x 3/4" USS bolt Air spring to lower plate
2 99373005 3/8” lock washer Air spring to lower plate
