Part # 11281099

65-70 Impala Front CoolRide Kit


Components:

2

90006781

255c air spring

2

90000052

Upper air spring cup bracket (4.5” tall)

1

90000408

Lower air spring plate with shock mount

1

90000409

Lower air spring plate with shock mount


Hardware:

2

99435002

7/16” x 8” stud

Upper cup bracket to frame

2

99432001

7/16” USS Nylok nut

Upper cup bracket to frame

2

99433002

7/16” flat washer

Upper cup bracket to frame

8 99372002

3/8” USS Nylok nut

Air spring to cup & lower plate to control arm

4

99371004

3/8” x 1 ¼” uss bolt

Lower air spring plate to control arm

2

99371001

3/8” x 3/4" USS bolt

Air spring to lower plate

14

99373003

3/8” SAE flat washer

Air spring plate

2

99373005

3/8” lock washer

Air spring to lower plate
