5. Raise the assembly into the coil
spring pocket with the all thread
sticking through the upper washer.
Secure the assembly with a 7/16”
Nylok nut and flat washer.
6. Fasten the air spring to the
lower arm using a 3/8” x 3/4" bolt,
flat washer and lock washer.
7. Double check air spring
clearance through full suspension
travel.
8. Ride height on this air spring is
approximately 5” tall. This may
vary to driver preference.
