350 S. St. Charles St. Jasper, In. 47546

Ph. 812.482.2932 Fax 812.634.6632

www.ridetech.com

Part # 11314099

91-96 Impala Rear CoolRide Kit



Components:

2

90009000

Tapered sleeve air spring

2

90000059

Upper cup bracket

2

90000072

Lower cup bracket

2

90000224

Upper washer (4” diameter - may not be needed)


Hardware:

2

99435003

7/16” x 2” stud

Cup bracket to frame

2

99433002

7/16” flat washer

Cup bracket to frame

2

99432001

7/16” Nylok nut

Cup bracket to frame

6

99371001

3/8” x 3/4" USS bolt

Air spring mounting

6

99373003

3/8” SAE washer

Air spring mounting

6

99373005

3/8” lock washer

Air spring mounting
