Ridetech 11360999 - Manual

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
11330999 Front CoolRide kit for 73-87 C10 for use with StrongArms
2 90006873 F6873 Front air springs
2 90000060 A069c Upper air spring plate w/ lettered holes
2 90001083 DAY2061 Medium bump stops
2 90000472 A565 Aluminum bump stop extension
1 90000726 A980D Driver side bump stop plate
1 90000727 A980P Passenger side bump stop plate
8 99371004 3/8” x 1 ¼” USS bolt Upper air spring plate to frame
4 99371001 3/8” x 3/4" USS bolt Air spring to lower control arm/ bump stop
4 99373005 3/8” lock washer Air spring to lower control arm/ bump stop
12 99372002 3/8” nyloc nuts
24 99373003 3/8” flat washers
Note: Will only work with our lower StrongArms, will not work with factory arms.
