350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11371099
88-98 Chevy C-1500 Front CoolRide
For Use w/ Factory Lower Arms
Components:
2 90006873 8” diameter double convoluted air springs
2 90000024 Upper air spring cup bracket (Tall)
2 90000057 Lower air spring cup bracket (Short)
2 90001083 Medium bump stops w/ hardware
Hardware:
2 99435002 7/16” x 8” stud Upper cup to frame
2 99432001 7/16” USS Nylok nut Upper cup to frame
2 99433002 7/16” SAE flat washer Upper cup to frame
2 99371001 3/8 x ¾ USS bolt Air spring to lower bracket
4 99372002 3/8” USS Nylok nut Air spring mounting
6 99373003 3/8” SAE flat washer Air spring mounting
2 99373005 3/8” lock washer Air spring to lower cup
