350 S. St. Charles St. Jasper, In. 47546

Ph. 812.482.2932 Fax 812.634.6632

www.ridetech.com

Part # 11390999

82-03 S10 Front CoolRide Kit

For Use w/ Lower StrongArms

Components:

2

90006781

Air spring – double convoluted, 6.5” diameter, ¼” npt port

2

90000424

Upper air spring cup bracket (3.5” tall)

Hardware:

2

99371001

3/8” x 3/4" USS bolt

Air spring to lower cup bracket

2

99373005

3/8” lock washer

Air spring to lower cup bracket

4

99372002

3/8” USS Nylok nut

Air spring to upper cup bracket

6

99373003

3/8” SAE flat washer

Air spring mounting

2

99435001

7/16” x 6” USS stud

Upper cup to frame

2

99432001

7/16” USS Nylok nut

Upper cup to frame

2

99433002

7/16” flat washer

Upper cup to frame
