Ridetech 11163510 User Manual

Ridetech For the car

background image

350 S. St. Charles St. Jasper, In. 47546

Ph. 812.482.2932 Fax 812.634.6632

www.ridetech.com

Part # 11163510

67-69 GM “F” Body HQ Series Front Coil-Overs

For Use w/ StrongArms & RideTech Spindles

Shock Assembly:

2

24139999

3.6” stroke HQ Series threaded shock

2

90009989

2.75” rebound adjustable threaded stud top

2

90001994

.625” I.D. bearing

4

90001995

Bearing snap ring

Components:

2

59080650

Coil spring – 8” long / 650 # rate

2

90002313

2.75” stud top base

2

90002222

spring retainer kit

2

90001902

Aluminum cap for Delrin ball

2

90001903

Delrin ball upper half

2

90001904

Delrin ball lower half

4

70010828

Delrin Spring Washer

Hardware:

2

99562003

9/16” SAE Nylok jam nut

Stud top hardware
