Service view - exterior parts list – Alto-Shaam Drawer Warmers 3DN User Manual
Page 18
Drawer Warmer Installation/Operation/Service Manual • 16
MODEL >
500-1D
500-2D
500-3D
ITEM
DEScrIpTION
pArT NO. QTy pArT NO. QTy pArT NO. QTy
1
TOP COVER
1012473
1
1012473
1
1012473
1
2
REAR TRIM
1012665
1
1012674
1
1012446
1
3
RIVET, BLIND, #44, S/S 28
RI-2100
24
RI-2100
28
RI-2100
30
4
GASKET ADHESIVE 0.125 x 0.375 [lin ft]
GS-23622
8
GS-23622
8
GS-23622
8
5
BUSHING, STRAIGHT, STRAIN RELIEF
BU-3964
1
BU-3964
1
BU-3964
1
6
CORDSET, 120V - 5' (1524mm)
CD-3232
1
CD-3232
1
CD-3232
1
CORDSET, 208-240V - 8' (2438mm)
CD-3551
1
CD-3551
1
CD-3551
1
CORDSET, 230V - 8' (2438mm)
CD-3922
1
CD-3922
1
CD-3922
1
7
HI-LIMIT PROTECTION COVER
1003936
1
1003936
1
1003936
1
8
SCREW, M4-0.7X6MM PHIL
SC-22271
2
SC-22271
2
SC-22271
2
9
HI-LIMIT THERMOSTAT
TT-33476
1
TT-33476
1
TT-33476
1
10
INNER BACK PANEL
1012667
1
1012673
1
1012439
1
11
BRACKET, SENSOR MOUNTING
1008272
1
1008272
1
1008272
1
12
SENSOR, MOUNTING BLOCK
BK-27878
1
BK-27878
1
BK-27878
1
13
PROBE, TEMPERATURE SENSOR
PR-34494
1
PR-34494
1
PR-34494
1
14
SCREW, 6-32 X 1/2", NC PHIL, FLAT
SC-2239
2
SC-2239
2
SC-2239
2
15
ELEMENT, 320W, FOIL PAD HEATER
EL-29875
1
EL-29875
2
EL-29875
2
16
OUTER CASING
1012664
1
1012671
1
1012445
1
17
BEARING, DRAWER WARMER
BG-24890
2
BG-24890
4
BG-24890
6
18
SCREW,1/4-20 x 1-1/8" FLAT HD, BEARING MOUNT
SC-25018
2
SC-25018
4
SC-25018
6
19
DRAWER FRAME ASSEMBLY, COMPLETE
5013915
1
5013915
2
5013915
3
20
PAN, FULL SIZE, 20-3/4" x 12-3/4" x 6"
PN-25088
1
PN-25088
2
PN-25088
3
21
SWITCH, ROCKER, 125-277V, 20A
SW-34769
1
SW-34769
1
SW-34769
1
22
OVERLAY, CONTROL PANEL
PE-29685
1
PE-29685
1
PE-29685
1
23
CONTROL
CC-34970
1
CC-34970
1
CC-34970
1
24
FRONT TRIM STUD ASSEMBLY
5014253
1
5014255
1
5013914
1
25
ELECTRIC CHASSIS SPOT
5014441
1
5014441
1
5014441
1
26
CONNECTOR-5 CONDUCTOR
CR-34646
2
CR-34646
2
CR-34646
2
27
T-BLOCK
BK-3019
1
BK-3019
1
BK-3019
1
28*
BUSHING, 3/8" BLACK HOLE
BU-3419
1
BU-3419
1
BU-3419
1
29*
CONNECTOR, #12 FERRULE
CR-34830
3
CR-34830
3
CR-34830
3
30*
INSULATION
IN-2003
5
IN-2003
5
IN-2003
5
31*
NUT, HEX #8-32
NU-2296
3
NU-2296
3
NU-2296
3
32*
NUT, 6-32 HEX, S/S
NU-2361
4
NU-2361
4
NU-2361
4
33*
PLUG, 3/8" HOLE
PG-25574
1
PG-25574
1
PG-25574
1
34*
SCREW, 10-32" X 1/4" PAN HD GROUND
SC-2190
1
SC-2190
1
SC-2190
1
35*
SCREW, 6-32 X 1-1/4" ROUND HD
SC-2365
2
SC-2365
2
SC-2365
2
36*
SCREW, 8-32 x 1/4" PHIL
SC-2459
4
SC-2459
4
SC-2459
4
37*
WASHER, 6-32, FLAT, NYLON
WS-23148
1
WS-23148
1
WS-23148
1
38*
WASHER, INT. LOCK
WS-2467
1
WS-2467
1
WS-2467
1
S E r V I c E
D A N g E r
DIScONNEcT uNIT frOM
pOwEr SOurcE bEfOrE
cLEANINg Or SErVIcINg.
D A N g E r
LOcK-OuT Or pOST
brEAKEr pANEL uNTIL
SErVIcE wOrK hAS
bEEN cOMpLETED.
SErVIcE VIEw - ExTErIOr pArTS LIST
*
not
shown
