2
1. Raise the vehicle to a safe and comfortable working height. Use jack stands to support the vehicle
with the suspension hanging freely.
2. Support the axle and remove the leaf springs, shocks, pinion snubber, and tail pipes. Refer to the
factory service manual for proper disassemble procedures. Keep the factory upper shock bolts and
front leaf spring mounting bolts.
1. The pinion snubber mount must be
cut on the line shown in the picture. This
allows more clearance of the pinion for
maximum drop.
2. Remove the gas tank sending unit
wire from the tank and pull it into the
trunk.
3. This raised area around the gas tank
sending unit wire must be flattened to
allow the upper bar mount to sit against
the pan. The area marked in chalk can
either be pie cut, hammered flat and
welded back together or cut out
completely.
