Ridetech 11366799 - Manual (Page 2)

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
ABAR11013 Hardware Kit
8
5/8” x 6” SAE bolt Lower bridge to axle
8 5/8” SAE Nylok nut Lower bridge to axle
16 5/8” SAE flat washer Lower bridge to axle
3 5/16” x 2” USS bolt Panhard bar axle bracket
3 5/16” SAE flat washer Panhard bar axle bracket
3 5/16” lock washer Panhard bar axle bracket
9 5/8” x 2 ¾” SAE bolt 4 link bars and panhard bar
9 5/8” SAE Nylok jam nut 4 link bars and panhard bar
6 3/8” x 3/4" USS bolt Air spring mounts
6 3/8” SAE flat washer Air spring mounts
6 3/8” lock washer Air spring mounts
46 7/16” x 1 ¼” USS bolt C-Notch, bar frame mount and upper bridge
46 7/16” USS Nylok nut C-Notch, bar frame mount and upper bridge
92 7/16” SAE flat washer C-Notch, bar frame mount and upper bridge
1 5/16” x 1 ¼” USS bolt Brake line bracket
1 5/16” USS Nylok nut Brake line bracket
2 5/16” SAE flat washer Brake line bracket
1 7/16” USS Nylok nut Panhard bar stud
1 ½” x 1 ½” fender washer Panhard bar stud
