Connections and Wiring
15 NI-700 & NI-900 Hardware Reference Guide
Modes and Front Panel LED Blink Patterns
The following table lists the modes and blink patterns for the front panel LEDs associated with each
mode. These patterns are not evident until after the unit is powered.
Port Assignments and Functionality
The Port Assignments are as follows:
AXlink Port and LED
Both the NI-700 and NI-900 have an AXlink port and adjacent status LED (FIG. 1). This port allows the
NI to support AMX Legacy AXlink devices such as G3 touch panels (ex: CP4/A) and PosiTrack Pilot
devices. A green LED shows AXlink data activity. When the AXlink port is operating normally, blink
patterns include:
Off - No power, or the controller is not functioning properly
1 blink per second - Normal operation.
3 blinks per second - AXlink bus error. Check all AXlink bus connections.
Modes and LED Blink Patterns
LEDs and Blink Patterns
Mode Description
STATUS
(green)
OUTPUT
(red)
INPUT
(yellow)
OS Start Starting the operating system (OS). On On On
Boot On-board Master is booting. On Off On
Contacting DHCP
server On-board Master is contacting a DHCP
server for IP configuration information. On Off Fast Blink
Unknown DHCP
server On-board Master could not find the
DHCP server. Fast Blink Off Off
Downloading Boot
firmware Downloading Boot firmware to the
Master’s on-board flash memory.
Do not cycle power during this process! Fast Blink Fast Blink Fast Blink
No program running There is no program loaded, or the
program is disabled. On Normal Normal
Normal On-board Master is functioning normally. 1 blink per second Indicates
activity
Indicates
activity
NI-700 Port Assignments NI-900 Port Assignments
Port ICSP Port # Port ICSP Port #
Serial Port #1 1 Serial Port #1 1
Serial Port #2 2 IR/Serial Port #1 2
IR/Serial Port 3 IR/Serial Port #2 3
I/O Port 4 IR/Serial Port #3 4
IR RX Port 5 I/O Port 5
IR RX Port 6
