Introduction
8 NI-700 & NI-900 Hardware Reference Guide
NI-900 Port Assignment And Functionality
NI-900 Specifications (Cont.)
Rear Panel Components (Cont.):
Ethernet Link/
Activity LED • Ethernet Port: RJ-45 port for 10/100 Mbps communication. LEDs show
communication activity, connection status, speeds, and mode information:
SPD (speed) - Yellow LED lights On when the connection speed is
100 Mbps and turns Off when the speed is 10 Mbps.
L/A (link/activity) - Green LED lights On when the Ethernet cables are
connected and terminated correctly, and blinks when receiving Ethernet
data packets.
Power port • 2-pin 3.5 mm mini-Phoenix (male) connector.
• Use a 12 VDC-compliant power supply to provide power to the NI-900
through the 2-pin 3.5 mm mini-Phoenix connector on the rear panel.
Operating Environment: • Operating Temperature: 0° C (32° F) to 50° C (122° F)
• Operating Humidity: 20% - 85% RH
Included Accessories: • 2-pin 3.5 mm mini-Phoenix female PWR connector (41-5025)
• 6-pin 3.5 mm mini-Phoenix female I/O connector (41-5063)
• NI-900 Quick Start Guide
• Three CC-NIRC IR Emitters
• Two 4-pin 3.5 mm mini-Phoenix female connector (41-5047)
Other AMX Equipment: • AC-RK Accessory Rack Kit (FG515)
• CC-NIRC IR cables (FG10-000-11)
• CC-NSER IR/Serial cables (FG10-007-10)
• CSB Cable Support Bracket (FG517)
• IRX-DM+ IR Sensor (FG458-10 and FG458-11)
• IRX-SM+ IR Sensor (FG455-01)
• PMB Pole Mount Bracket (FG531)
• STS, Serial To Screw Terminal (FG959)
• Surface Mount Bracket Accessory (FG525)
NI-900 Port Assignments
Port ICSP Port #
Serial Port #1 1
IR/Serial Port #1 2
IR/Serial Port #2 3
IR/Serial Port #3 4
I/O Port 5
IR RX Port 6
