DESCRIPTION
This section provides a description of the ACE-142S/142V cabinet plus specifications. Also
included is a listing of the various accessories and kits.
1.1
ACE-142S/142V Cabinet
The ACE-142S/142V cabinet is a secure, above-ground, outdoor fiber optic distribution cabinet
that is designed to hold the splice trays, splitters, connector panels, and connector storage panel
required for various Fiber To The Premises (FTTP) applications. A typical ACE-142S/142V
cabinet (with splitter modules and connector panels installed) is shown in
.
Figure 1. Typical ACE-142S/142V Cabinet
19620-A
RADIUS LIMITERS
FOR SPLITTER
OUTPUT FIBER
SLACK STORAGE
SPLITTER
MODULES
CONNECTOR
STORAGE PANEL
(PARKING LOT)
CONNECTOR
PANELS
FRONT
DISTRIBUTION
CABLE
SPLICE TRAYS
REAR
FEEDER CABLE
SPLICE TRAYS
CABLE
CLAMPS
