Figure 15, Figure 16 – ADC ACE-142S/142V User Manual
Page 31
ADCP-96-015 • Issue 1 • July 2004
Page 25
© 2004, ADC Telecommunications, Inc.
Figure 15. Cable Clamp Assembly for Feeder Cable
Figure 16. Feeder Cable Fibers Routed To Splice Trays
CABLE
USE GROMMET
FOR SMALLER
DIAMETER CABLES
COVER
PLATE
CLAMPS
SCREWS
19623-A
SECURE FEEDER CABLE
TO PANEL ON RIGHT
SIDE OF CABINET
SPLITTER INPUT
FIBER ROUTING
CENTER PANEL
TIE POINT
CABLE
CLAMP
SECURE FEEDER CABLE
AND SPLITTER INPUT FIBERS
TOGETHER AT THIS POINT
19625-A
FEEDER CABLE
SPLICE TRAYS
