COMPRESSOR
THRESHOLD AT MAXIMUM
MED ATTACK / MEDIUM RELEASE
SHOWS 3:1 SLOPE
LIMITER
THRESHOLD AT MAXIMUM
Slope starts at 5:1 quickly becomes 10:1
then towards 20 dB of limiting begins to
return to normal. Opto has 20 dB range
DE-ESSER NOTCHES ( the sense filters are shown
are 3K and 12K) METER SHOWS NOTCH DEPTH
1.25 2K 2K5 1K6 4K 5K 8K 10K 12K5 3K1 16K 20K 25K 6K2
3K 6K
25
9K
12K
MORE VOXBOX CURVES
