Manley VOXBOX - MVBXA 4/2003 User Manual
Page 2
CONTENTS
SECTION
PAGE
INTRODUCTION 3
QUICK START
4
MAINS CONNECTIONS
5
FRONT PANEL
MIC
PRE
6
COMPRESSOR
7
EQ
&
DE-ESSER
8
REAR PANEL
9
GENERAL DISCUSSION
OVERVIEW AND BLOCK DIAGRAM
12
MIC PREAMP & COMPRESSOR
13
EQ & DE-ESSER
15
ADDENDUM 18
TECHNICAL DETAILS
TUBE, TRIMMER LOCATIONS
19
CALIBRATION 20
TROUBLESHOOTING 21
SPECIFICATIONS 23
CURVES 24
APPENDIX 1 - TEMPLATE FOR STORING SETTINGS
26
