Trinity PID list Page 30
Engine Torque (40TE/41TE/42RLE) ENG TRQ RLE lbft
Status
MDS Status MDS Status
Throttle
BASE IDLE SPD BASE IDLE SPD rpm
DES PID IDLE SPD DES PID IDLE SPD rpm
Throttle Position Sensor Voltage THR POS V Volts
Throttle Position Sensor Percent THR POS % %
Target Idle Speed Target Idle Speed rpm
Throttle Blade Position THR BLADE %
Accelerator Pedal Position ACC PDL POS %
Change in Pedal Position Voltage
above its Minimum Threshold Change in Pedal Position Voltage
above its Minimum Threshold
Volts
HEV Target Idle Speed HEV Target Idle Speed rpm
TA IDLE LOOP FIN AVG TIME TA IDLE LOOP FIN AVG TIME ns
TA IDLE LOOP FIN MAX TIME TA IDLE LOOP FIN MAX TIME ns
TA IDLE LOOP FIN MIN TIME TA IDLE LOOP FIN MIN TIME ns
Pedal Value Sensor 1 Max Value
Stored Pedal Value Sensor 1 Max Value
Stored
Volts
Pedal Value Sensor 2 Max Value
Stored Pedal Value Sensor 2 Max Value
Stored
Volts
Raw throttle input Raw throttle input Volts
Throttle Angle Data THR ANGLE Deg
Throttle Error Intermittent Counter Throttle Error Intermittent Counter Counts
Throttle Input Signal High Fault
Counter Throttle Input Signal High Fault
Counter
Counts
Throttle Input Signal Low Fault
Counter Throttle Input Signal Low Fault
Counter
Counts
Transmission
Trans Oil Temperature TRANS OIL TEMP F
Trans Engine Speed Trans Engine Speed rpm
Turbine Torque I‐Gear Turbine Torque I‐Gear lbft
