Trinity PID list Page 3
VTASKIM VTA SKIM Status On/Off
Diagnostic 2
VTASKIM2 VTA SKIM Status On/Off
AirPres Ambient Air Pressure in Hg
AirPresV Ambient Air Pressure sensor volts
AirTempF Ambient Air Temperature F
AirTempV Ambient Air Temperature sensor volts
Cyl1 Cylinder Contribution 1 %
Cyl5
Cylinder Contribution 2 (percent contribution from
physical cylinder 5)
%
Cyl3
Cylinder Contribution 3 (percent contribution from
physical cylinder 3)
%
Cyl6
Cylinder Contribution 4 (percent contribution from
physical cylinder 6)
%
Cyl2
Cylinder Contribution 5 (percent contribution from
physical cylinder 2)
%
Cyl4
Cylinder Contribution 6 (percent contribution from
physical cylinder 4)
%
Cyl1‐3
Cylinder Bank Contribution 1 (percent contribution
from physical cylinders 1‐3)
%
Cyl4‐6
Cylinder Bank Contribution 2 (percent contribution
from physical cylinders 4‐6)
%
CylTest Cylinder Performance Test On/Off
HPSVTest HPSV Test Active On/Off
History And Trip Data
TotalFuel Total Fuel Used gal
TripFuel Trip Fuel Used gal
TotalTime Total Time hours
TripTime Trip Time hours
IdleFuel Total Idle Fuel Used gal
TripIdle Trip Idle Fuel Used gal
IdleTime Total Idle Time hours
TripIdle Trip Idle Time hours
Dist Total Distance mile
TripDist Trip Total Distance mile
TripEconomy Trip Average Fuel Economy mpg
ECMTime ECM Run Time s
EngTime Engine Run Time s
Tuning 1
EngSpd Engine Speed rpm
TransOil Transmission oil temperature F
Spd Vehicle speed mph
ThrPos Throttle position %
ThrPosIdl Throttle position before idle validation %
TransOil Transmission oil temperature sensor volts
TransGov Transmission governor pressure psi
Coolant Engine coolant temperature F
CoolantV Engine coolant temperature sensor volts
Boost Boost pressure psi
Intake Intake air temperature F
IntakeV Intake air temperature sensor volts
Battery Battery Voltage volts
TransShaft Transmission output shaft speed rpm
WaterFuel Water in fuel counts
VFSPWM Transmission VFS PWM duty cycle %
FinalFuel Final fueling
4DFuel 4D fueling table output
AFCFuel AFC fueling table output
LSGFuel LSG fueling output
Tuning 2
ASGFuel ASG fueling output
HSGFuel HSG fueling output
TarGovPres Target governor pressure psi_g
Pedal Pedal Position Sensor 1 %
PedalV Pedal Position Sensor 1 voltage volts
4DOut 4D timing table output Deg
AFCInc AFC timing increment Deg
MisfireMin Misfire minimum timing Deg
PedalPos2 Pedal Position Sensor 2 %
PedalPos2V Pedal Position Sensor 2 voltage volts
WGDuty Wastegate duty cycle %
MAPV MAP sensor volts
WaterV Water in fuel sensor volts
%Load Percent Load %
MaxFuelCal The calibrated maximum fueling that the system may output
MaxSpd100
The calibrated maximum engine speed for 100
percent throttle
rpm
MaxSpd0
The calibrated maximum engine speed for zero
percent throttle
rpm
IntkHeater Intake Air Heater Control Status
AirPres Initial ambient air pressure psi
Misfire Misfire Total Attempts Number counts
Tuning 3
IAHTemp IAH Temperature Input0 F
CTIRDelta CTIR Delta Temperature F
