Trinity PID list Page 26
1/2 O2 Min Threshold Type 1/2 O2 Min Threshold Type
Last 2/2 O2 High Volt Last 2/2 O2 High Volt Volts
Last 2/2 O2 High Volt Spec Last 2/2 O2 High Volt Spec Volts
2/2 O2 Mon Max Status 2/2 O2 Mon Max Status
2/2 O2 Max Threshold Type 2/2 O2 Max Threshold Type
Last 2/2 O2 Low Volt Last 2/2 O2 Low Volt Volts
2/2 O2 Low Volt Spec 2/2 O2 Low Volt Spec Volts
2/2 O2 Mon Min Status 2/2 O2 Mon Min Status
TM O2 MON 1 IN USE REG TM O2 MON 1 IN USE REG
O2 Monitor Bank 1 Ratio O2 Monitor Bank 1 Ratio Ratio
O2 Monitor Bank 1 Numerator O2 Monitor Bank 1 Numerator
O2 Monitor Bank 1 Denominator O2 Monitor Bank 1 Denominator
TM O2 MON 2 IN USE REG TM O2 MON 2 IN USE REG
O2 Monitor Bank 2 Ratio O2 Monitor Bank 2 Ratio Ratio
O2 Monitor Bank 2 Numerator O2 Monitor Bank 2 Numerator
O2 Monitor Bank 2 Denominator O2 Monitor Bank 2 Denominator
ENV MAX ARM O2 FACTOR ENV MAX ARM O2 FACTOR Mult
ENV MAX O2 SIGNAL 1 ENV MAX O2 SIGNAL 1 Volts
ENV MAX TEST O2 FACTOR ENV MAX TEST O2 FACTOR Mult
ENV MIN ARM O2 FACTOR ENV MIN ARM O2 FACTOR Mult
ENV MIN O2 SIGNAL 1 ENV MIN O2 SIGNAL 1 Volts
ENV MIN TEST O2 FACTOR ENV MIN TEST O2 FACTOR Mult
ENV O2 F2 OUT OF RANGE TIME ENV O2 F2 OUT OF RANGE TIME s
ENV O2 FACTOR LOOP TIME ENV O2 FACTOR LOOP TIME s
ENV O2 FILTER CONSTANT ENV O2 FILTER CONSTANT Mult
ENV O2 LOC 11 OUT OF RANGE TIME ENV O2 LOC 11 OUT OF RANGE TIME s
Purge #2 AirFlow Purge #2 AirFlow g/s
O2 SENSOR 1 A2D OFFSET O2 SENSOR 1 A2D OFFSET Counts
O2 SENSOR 1 A2D SLOPE O2 SENSOR 1 A2D SLOPE Counts
O2 SENSOR 2 A2D OFFSET O2 SENSOR 2 A2D OFFSET Counts
O2 SENSOR 2 A2D SLOPE O2 SENSOR 2 A2D SLOPE Counts
O2 SENSOR 3 A2D OFFSET O2 SENSOR 3 A2D OFFSET Counts
O2 SENSOR 3 A2D SLOPE O2 SENSOR 3 A2D SLOPE Counts
O2 SENSOR 4 A2D OFFSET O2 SENSOR 4 A2D OFFSET Counts
O2 SENSOR 4 A2D SLOPE O2 SENSOR 4 A2D SLOPE Counts
O2 HEAT SENSOR 1 OFFSET COMP O2 HEAT SENSOR 1 OFFSET COMP Counts
O2 HEAT SENSOR 1 SLOPE COMP O2 HEAT SENSOR 1 SLOPE COMP Counts
O2 HEAT SENSOR 2 OFFSET COMP O2 HEAT SENSOR 2 OFFSET COMP Counts
O2 HEAT SENSOR 2 SLOPE COMP O2 HEAT SENSOR 2 SLOPE COMP Counts
O2 HEAT SENSOR 3 OFFSET COMP O2 HEAT SENSOR 3 OFFSET COMP Counts
O2 HEAT SENSOR 3 SLOPE COMP O2 HEAT SENSOR 3 SLOPE COMP Counts
O2 HEAT SENSOR 4 OFFSET COMP O2 HEAT SENSOR 4 OFFSET COMP Counts
O2 HEAT SENSOR 4 SLOPE COMP O2 HEAT SENSOR 4 SLOPE COMP Counts
Manifold absolute pressure MAP ABS in Hg
Miscellaneous
MAP V MAP V Volts
ACCUM AIR PORT MASS FLOW ACC AIR PORT MASS FLOW g
MAP Vacuum MAP VAC in Hg
P‐Ratio MAP/BARO P‐RAT MAP BARO PRatio
TOTAL PORT MASS FLOW SCALED TOT PORT MASS FLOW SCALED g/s
Minimum TPS Minimum TPS Volts
DELTHR DELTHR Volts
THR POSN 10BIT THR POSN 10BIT Volts
START ECT START ECT F
ECT PREVIOUS ECT PREVIOUS F
SHUT DOWN ECT SHUT DOWN ECT F
NUMBER OF EPPS NUMBER OF EPPS Counts
Time From Start Run Time From Start Run s
Closed Loop Timer Closed Loop Timer s
O2S 11 DELAY AFTER OPEN LOOP TMR O2S 11 DELAY AFTER OPEN LOOP TMR s
O2S 11 KICK O2S 11 KICK Mult
O2S 11 KICK LEAN O2S 11 KICK LEAN Mult
O2S 11 PROP O2S 11 PROP Mult
O2S 11 PROP GAIN O2S 11 PROP GAIN 1/V
O2S 11 INTGL GAIN O2S 11 INTGL GAIN 1/kV
O2S 11 DERIV O2S 11 DERIV Mult
O2S 11 DERIV ERROR O2S 11 DERIV ERROR Volts
O2S 21 SIGNAL LIN O2S 21 SIGNAL LIN Volts
O2S 21 CLOOP TIME FROM START O2S 21 CLOOP TIME FROM START s
O2S 21 DELAY AFTER OPEN LOOP TMR O2S 21 DELAY AFTER OPEN LOOP TMR s
O2S 21 KICK O2S 21 KICK Mult
O2S 21 KICK LEAN O2S 21 KICK LEAN Mult
O2S 21 KICK RICH O2S 21 KICK RICH Mult
O2S 21 PROP O2S 21 PROP Mult
O2S 21 PROP GAIN O2S 21 PROP GAIN 1/V
O2S 21 INTGL GAIN O2S 21 INTGL GAIN 1/kV
O2S 21 DERIV O2S 21 DERIV Mult
O2S 21 DERIV ERROR O2S 21 DERIV ERROR Volts
O2S 12 SIGNAL LIN O2S 12 SIGNAL LIN Volts
O2S 12 DELAY AFTER OPEN LOOP TMR O2S 12 DELAY AFTER OPEN LOOP TMR s
O2S 12 ADAP O2S 12 ADAP Volts
DS ADAP TIME FROM START TIMER DS ADAP TIME FROM START TIMER s
