Ag-Bag MB10012HyPac User Manual
Page 49
49
P
ARTS
M
ANUAL
Ag-Bag International, Ltd.
MB10000 July 2003
Appendix A
Steering - Parts List
Item#
Part#
Description
Qty.
Remarks
1
ref.
Cap Screw, Hex
4
3/8-16NC 1-1/2
2
ref.
Washer, Lock
4
5/8
3
1550245
Pin, Roll
4
4
1010088
Washer, Tie Rod
4
5
ref.
Tie Rod, Steering
1
Trailer end
6
ref.
Bushing, Bronze
4
1.25ID x 1.5OD x 1.660
7
ref.
Zerk, Grease
4
Press in
8
1550331
Cap Screw, Hex
10
3/4-10NC x 2-1/2 G8
9
ref.
Washer, Lock
10
3/4
10
ref.
Bracket, Steering cylinder
2
11
1010089
Shim, Steering cylinder bracket
ref.
12
ref.
Pin, Clevis
4
13
ref.
Pin, Hair cotter
4
14
1540102
Cylinder, Hydraulic
2
15
ref.
Tie Rod, Steering
1
Towing end
