Ag-Bag MB10012HyPac User Manual
Page 21
21
P
ARTS
M
ANUAL
Ag-Bag International, Ltd.
MB10000 July 2003
Appendix A
Item#
Part#
Description
Qty.
Remarks
1
1201023
Spacer, Wheel Column Bronze
1
5-inch
2
1201016
Wheel Column, Drive
1
3
ref.
Cap Screw, Hex
2
3/8-16NC x 2-1/2
4
ref.
Washer, Brake Shoe
8
5
ref.
Ring, Snap
4
6
1010059
Cam, “S” Modified
1
7
1501183
Shoe, Brake
2
8
ref.
Roller, Brake Shoe
2
9
ref.
Retainer, Brake Shoe Roller
2
10
1502240
Spring, Brake Shoe Return
1
11
ref.
Bushing, Brake Shoe Pin
2
12
ref.
Pin, Brake Shoe
2
1501178
Kit, Brake Repair Parts
ref
13
ref.
Cap Screw, Hex
8
3/8-16NC x 2
14
ref
Washer, Split Lock
8
3/8
15
1010058
Spider, Brake Modified
1
16
ref.
Nut, Hex
2
5/8-11NC
17
ref.
Washer, Split Lock
10
5/8
18
1501185
Clevis, Air Can
1
19
1501184
Can, Air
1
1541415
Tubing, Air Brake
1
20
ref.
Pin, Air Can Clevis
1
21
ref.
Pin, Cotter
1
22
ref.
Cap Screw, Hex
4
1/2-13NC x 3-3/4
23
ref.
Washer, Split Lock
4
1/2
24
1550381
Ring, Snap
1
25
1550380
Washer, Cam
1
26
1501180
Adjuster, Slack
1
27
1501189
Seal, Cam Brake
1
28
1501190
Bushing, Cam
1
29
1201012
Bracket, “S” Cam Shaft
1
30
ref.
Cap Screw, Hex
8
M16 x 60
31
1541416
Fitting, Air
1
32
ref.
Nut, Hex
2
3/8-16NC Lock
33
1550411
Nut, Hex Jam
10
12 x 1-3/4 MM
34
1010057
Drum, Brake 16-1/2 Modified
1
35
1550360
Cap Screw, Socket Head
10
1/2 x 1-3/4 x 90
36
1201018
Drive, Wheel Class 5
1
Black Bruin Machined
Wheel - Brake Group Parts List
